Product Detail

IVA

Share to：

IVA

Details

材质

Carbon steel

类型

GB

Item	Dimentions					Screw		质量 W.t
	D	H	g	t	d1	Screw		质量 W.t
	mm	mm	mm	mm	mm	n-m	N.m	g
IVA M8x0.75	16	8	3	2	11	2-M4	3.5	4
IVA M10x0.75	18	8	3	2	13	2-M4	3.5	8
IVA M10x1	18	8	3	2	13	2-M4	3.5	8
IVA M12x1	22	8	3	2	16	2-M4	3.5	14
IVA M15x1	25	8	3	2	20	2-M4	3.5	18
IVA M17x1	28	10	4	2	23	2-M5	4.5	28
IVA M20x1	32	10	4	2	26	3-M5	4.5	34
IVA M22x1	38	10	4	3	27	3-M4	3.5	52
IVA M25x1.5	38	12	5	2	32	3-M6	8.0	58
IVA M30x1.5	45	12	5	2	39	3-M6	8.0	78
IVA M35x1.5	52	12	5	2	46	3-M6	8.0	104
IVA M40x1.5	58	14	6	2.5	51	3-M6	8.0	148
IVA M45x1.5	65	14	6	2.5	58	3-M6	8.0	184
IVA M50x1.5	70	14	6	2.5	63	3-M6	8.0	200
IVA M55x2	75	16	7	3	67	3-M8	18.0	246
IVA M60x2	80	16	7	3	72	3-M8	18.0	270
IVA M65x2	85	16	7	3	77	3-M8	18.0	290
IVA M70x2	92	18	8	3.5	83	3-M8	18.0	398
IVA M75x2	98	18	8	3.5	89	3-M8	18.0	434
IVA M80x2	105	18	8	3.5	96	3-M8	18.0	504
IVA M85x2	110	18	8	3.5	101	3-M8	18.0	532
IVA M90x2	120	20	10	4	108	3-M8	18.0	762
IVA M95x2	125	20	10	4	113	3-M8	18.0	796
IVA M100x2	130	20	10	4	118	3-M8	18.0	836
IVA M105x2	140	22	12	5	125	3-M8	18.0	1130
IVA M110x2	145	22	12	5	132	3-M8	18.0	1172
IVA M115x2	150	22	12	5	137	3-M8	18.0	1270
IVA M120x2	155	24	12	5	142	3-M8	18.0	1390
IVA M125x2	160	24	12	5	147	3-M8	18.0	1450
IVA M130x2	165	24	12	5	152	3-M8	18.0	1500
IVA M135x2	175	26	14	6	160	3-M10	35.0	1930
IVA M140x2	180	26	14	6	165	3-M10	35.0	1950
IVA M145x2	190	26	14	6	175	3-M10	35.0	2380
IVA M150x2	195	26	14	6	180	3-M10	35.0	2440
IVA M155x3	200	28	16	7	180	3-M10	35.0	2760
IVA M160x3	210	28	16	7	190	3-M10	35.0	3160
IVA M165x3	210	28	16	7	190	3-M10	35.0	3300
IVA M170x3	220	28	16	7	200	3-M10	35.0	3315
IVA M180x3	230	30	18	8	205	3-M12	60.0	3690
IVA M190x3	240	30	18	8	215	3-M12	60.0	3880
IVA M200x3	250	32	18	8	225	3-M12	60.0	4370

Apply to： Supporting facilities for ports,metallurgy,coal mines,electric motors,textiles......and various mechanical manufacturing.
